CNC Machine Center RC1530S-ATC
The video about CNC Machine Center RC1530S-ATC
Syntec Controller, Yaskawa Servo Motor and Driver, Italian HSD Air cooling ATC spindle.
CarouselTool Magazine, saving more processing time than traditional ones. According to different work, we can provide the carousel tool magaine with 8,12 or 16 tool holder forks.
With automatically pushing function, it can connect the auto loading and unloading platform, for reducing labor cost and saving time.
Intelligent processing cross-border protection function can prevent the excessive processing caused by mechanical collision.
Technical Parameter of CNC Machine Center RC1530S-ATC
| X,Y,Z Working Area | 1500x3000x250mm |
| Table Size | 1560×3440mm |
| X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
| X,Y,Z Repositioning Accuracy | ±0.03mm |
| Table Surface | Vacuum and T-slot Combined |
| Frame | Welded structure |
| X, Y Structure | Rack and Pinion Drive |
| Z Structure | Hiwin Linear Rails and Ball Screw |
| Max. Power Consumption | (Without Spindle) 4.5kw |
| Max. Rapid Travel Rate | 45000mm/min |
| Max. Working Speed | 30000mm/min |
| Spindle Power | 9.6kw |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Yaskawa servo |
| Working Voltage | AC 380V/50/60Hz,3PH |
| Command Language | G Code |
| Operating System | Syntec Control System |
| Computer Interface | USB |
| Flash Memory | 128M(U Disk) |
| Collet | ER32 |
| X,Y Resolution | <0.03mm |
| Software Compatibility | Type3/ Artcam software |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
| Packing Size | 3700X2250X2250mm |
| N.W. | 2600KG |
| G.W. | 2650KG |
| Optional Parts | Dust Collector,Vacuum Pump,Rotary System |
——— END
Contact us for detailed information of CNC Machine Center RC1530S-ATC
What is CNC Machine Center RC1530S-ATC?
What is the cost of CNC Machine Center RC1530S-ATC?
What is the life span of CNC Machine Center RC1530S-ATC?
The customer who inquired
- Elizabeth Inquire 29 minutes ago
- James Inquire 23 hours ago
- Sarah Inquire 20 days ago
- Michael Inquire 18 days ago
- Emily Inquire 3 days ago
- William Inquire 5 days ago
- Amelia Inquire 10 days ago
- Benjamin Inquire 22 days ago
- Grace Inquire 23 days ago
- Logan Inquire 23 days ago
- Henry Inquire 23 days ago
- Mia Inquire 15 days ago
- Jackson Inquire 20 days ago
- Charlotte Inquire 13 days ago
- Lucas Inquire 13 days ago
- Amelia Inquire 30 days ago
- Aiden Inquire 19 days ago
- Harper Inquire 8 days ago
- Caden Inquire 30 days ago
- Evelyn Inquire 24 days ago
- Grayson Inquire 4 days ago
Previous：4-Axis CNC Router RC1325RH-ATC
Next：CNC Router 1530-ATC
Top Reviews
Related Articles
-
From Three Axes to Five: The Quiet Restructuring of Woodworking CNC Machining CentersAbstract — The woodworking and panel-furniture machinery sector has, over the past decade,...Sep 23 , 2024 -
Automated Nesting and Five-Axis Machining: How CNC Equipment Makers Are Reshaping Panel Furniture and Complex-Curve ProductionAbstractThe economics of modern furniture and fabrication work increasingly hinge on how m...Sep 23 , 2024 -
The Industrialization of Multi-Axis CNC: Five-Axis Machining Centers in Mold, Woodworking, and Stone Fabrication. Five-axis simultaneous machining has moved out of the aerospace tool room and into the c...Sep 23 , 2024 -
Precision at the Edge: How CNC Stone Carving Automation Is Reshaping Modern FabricationStone has always been an awkward material for automation. It is abrasive, heavy, and unfor...Sep 23 , 2024
Core Component Comparison — CNC Machine Center RC1530S-ATC
| Component | Brand / Specification |
|---|---|
| Spindle | Italian HSD 9.0kW (air-cooled / ATC optional) |
| Servo Motor & Driver | Yaskawa (Japan) |
| Reducer | Shimpo / Apex |
| Controller / CNC System | Taiwan Syntec / LNC |
| Linear Guide | HIWIN / PMI (Taiwan) |
| Inverter (VFD) | Delta (Taiwan) |
| Rack & Pinion | APEX / HERION (Germany) |
| Electrical Parts | Schneider / CHINT |
| Warranty | 2 Years on core parts |
* Typical industrial-grade configuration; final BOM is confirmed by order specification.
Frequently Asked Questions
Q1. What certifications does the CNC Machine Center RC1530S-ATC have?
The CNC Machine Center RC1530S-ATC is manufactured under a CE, ISO9001 and FDA certified quality system, ensuring compliance with international safety and quality standards.
Q2. What is the warranty and after-sales support?
We provide a 2-year warranty on core components, lifetime technical support, free remote diagnosis, and a guaranteed supply of original spare parts.
Q3. Can the CNC Machine Center RC1530S-ATC be customized to my production needs?
Yes. We offer OEM/ODM customization including working size, spindle or laser power, automatic tool changer, rotary axis, and full automation integration based on your material and throughput.
Q4. What is the lead time and shipping method?
Standard models are ready to ship in 15-25 working days. We arrange worldwide sea or air freight with reinforced export packaging and full documentation.
Q5. Do you provide installation and operator training?
Yes. We supply free remote installation guidance, step-by-step training videos, and on-site service is available upon request.
Q6. Are spare parts and consumables available?
Yes. We keep a long-term stock of original spare parts and common consumables and can dispatch them by express worldwide.
Comment content：Hello, I am looking for a 4 axis /swing head/ router... 4 Axis 2040 600Z ATC /swing head/ wood 3d router 2040 table with 600 mm Z axis (or 1540) Vacuum and T-slot Syntec 21 MB controller Yaskawa .850 servos HQD ATC 9.0 kw Chinese Spindle Z sensor 8 or 12 linear tool rack 30 mm Hiwin glides (X & Y) 25 mm Z / Shimpo or Motovario (planetary reducers) Helical Rack and Pinion (X and Y) Ball screw (Z) Limit switches at both ends of the X & Y axis (soft - Omron) Manual or Autolube system Coolant attachment (for non ferrous metals) 2 - vacuum pumps air 7.5 kw Yongdun 30% down - Payment through Alibaba Shipping (CIF) to the Port of Tampa, Florida, USA Balance of payment after machine inspection in Jinan Assembly, set up, troubleshooting and operation training at your factory Thank You, Paul Chabot
