CNC Router RC1325S-ATC

CNC Router RC1325S-ATC

Find Details and Price about CNC Router RC1325S-ATC,The automatic push function of CNC ROUTER RC1325S-ATC can be used together with the loading and unloading platform to save unloading time and improve processing efficiency. CNC ROU......
Model:RC1325S-ATC
Category:ATC CNC Routers
Brand:Roctech®
Inquiry CNC Router RC1325S-ATC Price
The case about CNC Router RC1325S-ATC
  1. Syntec Controller, Yaskawa Servo Motor and Driver, Italian HSD Air cooling ATC spindle.

  2. CarouselTool Magazine, saving more processing time than traditional ones. According to different work, we can provide the carousel tool magaine with 8,12 or 16 tool holder forks.

  3. With automatically pushing function, it can connect the auto loading and unloading platform, for reducing labor cost and saving time.

  4. Intelligent processing cross-border protection function can prevent the excessive processing caused by mechanical collision.

Technical Parameter of CNC Router RC1325S-ATC

Description

Parameter

X,Y,Z Working Area1300x2500x250mm
Table Size

1300×2500mm

X,Y,Z Traveling Positioning Accuracy

±0.03/300mm

X,Y,Z Repositioning Accuracy±0.03mm
Table SurfaceVacuum and T-slot Combined
Frame

Welded structure

X, Y Structure

Rack and Pinion Drive

Z Structure

Hiwin Linear Rails and Ball Screw

Max. Power Consumption(Without Spindle) 4.5kw
Max. Rapid Travel Rate

45000mm/min

Max. Working Speed

30000mm/min

Spindle Power9kw
Spindle Speed

0-24000RPM

Drive MotorsYaskawa Servo Motor
Working VoltageAC 220V/50/60Hz,3PH
Command LanguageG Code
Operating System

Syntec Control System

Computer InterfaceUSB
Flash Memory

8GM(U Disk)

ColletER32
X,Y Resolution

<0.03mm

Software Compatibility

Type3/ Artcam software

Running Environment Temperature0 - 45 Centigrade
Relative Humidity30% - 75%
Packing Size3300X2200X2400mm
N.W.2200KG
G.W.2500KG
Optional Parts

Dust Collector,Vacuum Pump,Rotary System
